My name is Louis E. Routier, III.  In December of 2001, I began offering to prior employers and new clients engineering and drafting services based on my years of prior experience in manufacturing, quality control and engineering documentation.  Full specification and clear attention to detail on each scope of work has always been a standard rule maintained in prior years and after becoming self-employed.  It seems I have lived on AutoCAD almost every day since 1992 and today we are still using all Autodesk Applications for design work.  Finally, in 2011, I decided to give up some of that fun and hired a drafter.  It has worked out well, allowing us to do more in less time. Today we are still a team of two working in a low overhead environment and hopefully able to pass on savings to our clients. We think you will enjoy our process, our personality, and our commitment to quality work that is precise, poised and professional.

The “EP Paup” during construction, one of the heavy lift cranes for Manson Construction, built from a combination of new and recycled structures and equipment.

Below are some different projects that we have completed to give you a sense of our focus and versatility in design and engineering services. We've included a short description with each image so that you can understand the project and its purpose. These are Structural Design Packages with PE stamped Load Charts or Load Ratings where applicable:

Conversion from a single to a 2- part whip line on the “DB350” for Bisso Marine.

Anchor handling boom.  With some design rework, a new boom was built to replace the damaged original boom.

Damaged mast for a Manitowoc crawler crane.  Created a repair plan.

Pedestal design integrated into the boat deck for this crane installation.

Diver launch and recovery system (LARS) installations.

Equipment lift frame designed to meet offshore lifting criteria.

Aluminum tool box designed to meet offshore lifting criteria.

Offshore basket designed to meet offshore lifting criteria.

Personnel basket.

100 BBL Mud Tank. Designed to meet offshore lifting criteria.

Bridge operating machinery. Picture shows the box enclosed hoist for adjusting the bridge for tide changes.

Equipment skids. We created the client's arrangement drawing and P&ID to satisfy documentation requirements for their as-built skid.

Winch applications. We created performance specifications for the client and assisted with compiling a manual.

Tank piping installation for filling and draining marine transport tanks. We created arrangement drawings and P&ID to satisfy documentation requirements.
